Infrared photoelectric sensor smoke detector

General Details

Main features:

Operating voltage :3v lithium battery

Bettery life:10years

Infrared photoelectric sensor

MCU processing,eliminate false alarm,low batter warning

Low power consumption,test and hush button

Shockproof design ,

Dustproof,mothproof,anti-light interference design

Sound & flash alarm,Sound level 85db/3m

Low battery warning ,Test/hush function Tool-Free intallation design

Technical Parameter:

Model No.SR-808
Working voltage3V lithium battery  ( 10 years life)
Static current≤10uA
Alarm current≤60mA
Alarm outputSound & Flash Alarm
Sound level85dB/3m
InstallationCeiling mounted
Sensitivity1.8%/ft±0.8%/ft
Working environment-10℃~+50℃ (≤95%RH No congelation)
Dimension54*54*45mm
